SKU: NSCS40-200/110
Lowara NSCS40 200/110 Stainless Steel Heavy Duty Centrifugal Pump for High Pressure Supply with Closed Impeller
Australia-Wide
(08) 9240 2992
Official Lowara
Peace of Mind
Product Overview
Deployed specifically to combat thermal loads in expansive commercial infrastructures, the Lowara NSCS40-200/110 acts as a highly dependable facility cooling pump. Its rigid architecture provides excellent long-term serviceability and seamless volumetric transfer during continuous peak-demand cycles.
Supplied by an incredibly robust 11.0 kW / 415v three-phase electric motor, this unit achieves a maximum head of approximately 57.1 m and controls a massive maximum flow of approximately 1014 L/Min. The heavy-duty plumbing architecture utilizes a standard 65 mm suction connection and a 40 mm discharge line.
Internal hydraulic movement is expertly balanced through an optimized centrifugal casing that prioritizes raw output stability over long distances. The carefully machined impeller prevents severe pressure drop-offs during extreme operational loads, maintaining an even performance curve against substantial cooling loop resistance.
Combining a highly resilient Cast Iron external volute with a high-grade Fabricated Stainless Steel (AISI 316) impeller, it safely manages varying liquid temperatures up to +120 °C. The unit operates securely on a specialized stub shaft motor connection, providing strict alignment and comprehensive IP55 protection.
FEATURES
- High-strength rigid stub shaft motor bracket
- Highly durable Cast Iron external industrial casing
- Premium Fabricated AISI 316 Stainless Steel impeller
- Continuous duty fully enclosed three-phase motor
- Broad thermal tolerance for processing liquids up to +120 °C
- Dependable IP55 environmental moisture shielding
- Designed for highly stable continuous thermal duty
SPECIFICATIONS
| Max Flow | 1014 L/Min |
| Max Head | 57.1 m |
| Power | 11 kW / 415v |
| Rated Current | 19.2 Amps |
| Suitable For | Industrial Cooling Systems |
| Body Material | AISI 316 Stainless Steel |
| Liquid Temperature | -25°C to +120°C |
| Inlet Size | 65 mm |
| Outlet Size | 40 mm |
| Warranty | 12 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
Under commercial electrical service, what motor power in kilowatts and supply voltage feed power this flanged end-suction centrifugal pump?
Electrified by facility power panels, the NSCS40-200/110 connects to 380–415 V, 50 Hz, three-phase with an electric motor rated at 11 kW (15.0 HP) requiring 19.6 / 11.3 A.
What maximum working pressure capability in bar and liquid thermal boundaries are certified for this flanged end-suction centrifugal pump?
Maintaining under demanding fluid temperatures, the NSCS40-200-110 supports a maximum working pressure capability of 16 bar (PN 16) and liquid temperatures from -25°C to +120°C.
How high does water rise under the maximum dynamic head of this flanged end-suction centrifugal pump?
Pushing across building service lines, the NSCS40 200 110 generates a peak dynamic lift head of approximately 57.1 m under upward push.
What discharge flow volume in liters per minute and connection port dimensions apply to this flanged end-suction centrifugal pump?
Circulating across facility piping networks, the NSCS40_200_110 discharges a maximum delivery flow volume of approximately 1014 L/Min utilizing DN 65 suction and DN 40 discharge flanged ports.
What alloy metallurgy profile and mechanical face seal materials protect this flanged end-suction centrifugal pump against chemical attack?
Assembled with corrosion-resistant alloy materials, the NSCS40-200/110 combines alloy metallurgy of cast iron casing with stainless steel closed impellers with precision mechanical seals to defend against chemical attack.
