Lowara ECOCIRC-XL Plus 32-100 Bronze BMS Ready Circulator Pump for Solar Systems with ECM Motor
Australia-Wide
(08) 9240 2992
Official Lowara
Peace of Mind
Product Overview
Suitable for hot and cold HVAC loop circulation, geothermal loops, solar thermal, and secondary hot water systems, the Lowara ECOCIRC XL Plus 32-100 provides efficient service. This high efficiency wet rotor circulator pump combines ECM motor technology with comprehensive communication capabilities for building management system integration.
Performance delivers a maximum head of 10 m with flow capability reaching approximately 233 L/Min on 240 V single-phase supply. Four functional control modes including proportional pressure, constant pressure, constant speed, and differential temperature control enable optimisation for varying system requirements.
The bronze pump body is manufactured with ECM motor technology. The control interface features a clear display with error logging capability. Modbus RTU and BACnet protocols facilitate BMS communication, while the optional Wi-Fi module enables wireless connectivity. The electronics are isolated from the pump section to prevent condensation in chilled water applications.
Dry run protection safeguards against damage during no-water operation. Two analogue inputs accept 4-20 mA or 0-10 V signals for external control. An auxiliary temperature probe input allows differential temperature control for additional energy savings. Operating temperature range spans -10°C to +110°C with maximum ambient of +40°C.
FEATURES
- ECM motor for energy efficient circulation
- Modbus RTU and BACnet communication protocols for BMS integration
- Digital display with error log history for diagnostics
- Four control modes including differential temperature for energy savings
- Dry run protection preventing damage from waterless operation
- Two analogue inputs for 4-20 mA or 0-10 V external signals
- Optional Wi-Fi module for wireless communication
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What control modes are available to optimize energy usage?
The ECOCIRC-XL Plus 32-100 features proportional pressure, constant pressure, constant speed, and differential temperature modes.
Can I adjust this pump wirelessly using a smartphone or tablet?
Wireless programming is supported on the ECOCIRC-XL-Plus-32-100 when equipped with an optional Wi-Fi module.
How does the unit prevent internal moisture when circulating chilled water?
The ECOCIRC XL Plus 32 100 separates its electronic control block from the wet section to prevent condensation in chilled water loops.
What are the peak flow and head outputs for this circulator?
Reaching a maximum head of 10 m, the ECOCIRC_XL_Plus_32_100 provides flow rates up to approximately 233 L/Min.
Does this pump store fault records for maintenance troubleshooting?
The digital interface of the ECOCIRC-XL Plus 32-100 includes an error log history to simplify diagnostic and maintenance checks.
