SKU: DOMO15T
Lowara DOMO15T Stainless Steel IPX8 Rated Submersible Drainage Pump for Sump Emptying with Channel Impeller
Australia-Wide
(08) 9240 2992
Official Lowara
Peace of Mind
Product Overview
Addressing facility workloads and long-term operating costs, the DOMO 15T Channel Impeller model delivers an efficient extraction rate. This Lowara DOMO 15T utilizes a highly specific low-friction pathway developed to assist the draining of flooded basements, minimizing energy loss during continuous duty cycles.
The exterior architecture is composed entirely of 304 Stainless Steel, forming a protective boundary against environmental degradation. This premium housing strategy ensures the unit can be permanently submerged. The internal geometry safely conveys liquids containing suspended solids up to 50 mm in diameter.
Powered by a highly reliable 1.1 kW Three-phase 415v electrical assembly, the dry motor manages heavy mechanical loads by pulling a rated current of 2.73 Amps. The sealed casing uses the surrounding ambient fluid to dissipate heat effectively, preventing internal overheating and allowing operation right up to the maximum 35°C liquid temperature limit.
This robust fluid system reaches an impressive maximum flow of approximately 600 L/Min while maintaining a solid maximum head of 11 m. By utilizing 50 mm inlet and outlet connections, the pump ensures rapid liquid transit. The internal components are tightly protected from moisture infiltration by the DRIVELUB multiple seal system and a silicon carbide mechanical seal.
Features
- Utilizes a precision-engineered Channel Impeller for high-volume wastewater transit.
- Constructed from heavy-duty 304 Stainless Steel to resist chemical and physical wear.
- Protects internal drive systems via an advanced DRIVELUB multiple seal mechanism.
- Equipped with a highly resilient silicon carbide mechanical seal.
- Specifically engineered to safely process fluids containing large suspended solids.
- Utilizes a watertight dry motor configuration for stable thermal management.
- Rated with IPX8 protection and Class 155°C (F) electrical insulation.
SPECIFICATIONS
| Max Flow | 600 L/Min |
| Max Head | 11 m |
| Power | 1.1 kW / 415v |
| Rated Current | 2.73 Amps |
| Suitable For | Flooded basements |
| Body Material | 304 Stainless Steel |
| Liquid Temperature | Maximum 35°C |
| Outlet Size | 50 mm |
| Warranty | 12 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
How does this submersible sewage wastewater pump connect across power feeds regarding motor power in kilowatts and operating voltage?
Utilizing from dedicated power supplies, the DOMO15T relies on an electric motor rated at 1.1 kW (1.5 HP) energized via 380–415 V, 50 Hz, three-phase drawing 2.73 A.
In submerged wastewater applications, what maximum immersion depth and liquid temperature govern this submersible sewage wastewater pump?
Sustaining across submersible wastewater pits, the DOMO-15-T sustains a maximum 5 m immersion depth across fluid operating temperatures up to 35°C and accommodates 50 mm solids passage.
Across vertical plumbing risers, what peak dynamic elevation head does this submersible sewage wastewater pump achieve?
Attaining through distribution piping lines, the DOMO 15 T reaches a maximum dynamic elevation head of approximately 11 m across vertical runs.
For reliable piping integration, what maximum flow volume and connection port dimensions apply to this submersible sewage wastewater pump?
Transmitting through designated connection lines, the DOMO_15_T delivers a peak volumetric flow of approximately 600 L/Min via connected Rp 2" (50 mm) discharge threaded port.
What durable alloy metallurgy and mechanical face seal construction safeguard this submersible sewage wastewater pump against chemical attack?
Furnished for demanding fluid environments, the DOMO15T employs alloy construction of AISI 304 stainless steel motor casing and pump body with Drivelub mechanical seals with mechanical face seals to guard against chemical attack and corrosion.
