Onga PB5520 Extruded Carbon Block Lead & Cyst 0.5 Micron 4.5" x 20" Replacement Cartridge

Thick extruded carbon block technology defines this high-capacity cartridge, suitable for point-of-entry lead and cyst reduction.

Molded with specialized lead-adsorbing binders, the elongated carbon block media is supported by polypropylene end caps and high-temperature gaskets. The nominal dimensions are specified as 20 inches in length by 4.5 inches in outer diameter. The cartridge is independently certified to CSA Standard B483.1.

Lead and cyst reduction is performed mechanically through a nominal 0.5-micron rating, which captures microscopic pathogens including giardia and cryptosporidium. It operates on cold water lines with highest temperature capabilities up to 51.7 degrees Celsius, achieving significant chemical adsorption.

Positioned vertically in the second housing sump of the whole-house system, the element is identified by part number PB5520. It provides extended service life due to its elongated physical size and high carbon volume. Servicing guidelines recommend replacing the cartridge every 6 to 12 months depending on water usage.

• Extruded carbon block structure provides lead adsorption and chemical filtration.
• Tested and certified by NSF International to NSF/ANSI Standard 53.
• Polypropylene end caps provide stable sealing inside 20-inch sumps.
• Nominal 0.5-micron filtration rating captures giardia and cryptosporidium cysts.
• Resists chemical degradation and provides high chlorine odor reduction.
• Fits standard Big Blue 20-inch filter housings for point-of-entry loops.

Warranty: Pentair warrants this product against defects in materials and workmanship under normal use and service for a period of one year from the invoice date.
