Aussie Pumps GMP GB1KQ-A 24V 1" Ports Oil and Diesel Fuel Transfer Pump with 24V Electric Drive
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
Service trucks refuelling dump trucks and crawler tractors in the pit run this 24-volt transfer pump straight off the vehicle batteries, pushing up to 135 litres a minute with no mains supply in sight. Field refuelling lives or dies on battery power, and this unit is built for it. Battery-direct pit refuelling is ordered as GB1KQ-A 24V for 24-volt service fleets.
Open-discharge flow reaches 135 L/min, shutting off at 12 m head (17 PSI). The oil and diesel fuel-transfer wet end runs Viton seals fitted as standard for hydrocarbon resistance through compact 1" x 1" ports.
Drawing energy from the truck's own electrical system, the 1 kW 24 V drive spins the pump anywhere the service vehicle can park, with compact 1-inch ports keeping the installation tight. Open-air field refuelling is the rated environment, since the unit carries no ATEX certification for classified enclosures.
High-flow field refuelling of dump trucks and crawler tractors is the stated application for this compact transfer pump. It suits service vehicles, workshops and remote operating areas where equipment needs diesel or oil transferred directly into heavy plant without relying on a large fixed refuelling installation.
Features
- Vehicle-battery 1 kW 24 V drive powers true field refuelling with no mains supply anywhere on site.
- Open flow of 135 L/min, shutting off at 12 m (17 PSI) refuels dump trucks at a working pace.
- Hydrocarbon-ready Viton seals are fitted as standard equipment for oil and diesel transfer.
- Tight-mount 1-inch suction and discharge fit service-truck decks and pit bays easily.
- Open-air rating applies, since the unit is not ATEX certified for classified enclosures.
- Pit-proven brief centres on dump trucks and crawler tractors in field systems.
- Covered by the 3 year Aussie GMP warranty from installation.
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What peak delivery volume and vertical elevation pressure does this fuel pump achieve across transfer lines?
Operating across its performance curve, the Aussie Pumps DC Fuel B1KQ-A (GB1KQ-A-24V) discharges a maximum flow rate of approximately 135 L/min and develops a maximum elevation head of approximately 12 m.
What particle clearance does the open impeller allow when pumping diesel from storage tanks?
The GB1KQ A 24V transfers clean oil and diesel fuel through a cast iron wet end with Viton seals and carries no solids-handling rating.
How does direct current power operate this unit straight off service truck battery banks?
Direct current electrical power rated at 1 kW 24V drives the GB1KQ-A 24V, enabling field refuelling straight from vehicle battery banks without requiring inverters.
From what vertical intake depth can this unit draw diesel without pre filling lines?
Built-in priming passages on the GB1KQ-A 24V draw fuel vertically from depths down to 6 m without requiring an external foot valve once the casing is charged.
What mechanical seal metallurgy isolates the drive shaft during fuel transfer across service truck setups?
The wet end on the B1KQ-A (GB1KQ-A 24V) incorporates a Viton mechanical shaft seal, stopping leaks and resisting chemical attack from bulk diesel and motor oils.
