Aussie Pumps GMP GB3XR-A/X/1B50EM Mine Spec 316 Stainless Steel Semi-Trash Pump with Hatz Diesel Electric Start Engine
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
German diesel muscle drives this Mine Spec 316 stainless 3-inch trash pump, coupling an 11 HP Hatz electric-start engine to up to 1,500 litres a minute, shutting off at 30 metres. Stainless endurance meets Hatz reliability. Hatz reliability in Mine Spec stainless is GB3XR-A/X/1B50EM with 11 HP electric-start diesel.
Open-discharge flow reaches 1,500 L/min, shutting off at 30 m head (43 PSI). The 316 stainless steel B3XR-A/X wet end with open non-clog style impeller clears 24 mm solids through 80 mm ports.
Hatz reliability meets stainless endurance through the 11 HP Hatz diesel with electric start, coupled to Mine Spec 316 stainless hydraulics for up to 1,500 litres a minute, shutting off at 30 metres. Variable sump levels never trouble the self-priming suction.
Wastewater pumping, dust suppression, water-cart filling, fire-fighting supply and quarry dewatering are the main duties for this engine-driven unit. It suits contractors and quarry crews needing one portable pump for site water management, from clearing dirty water to supplying carts, suppression systems and fire-water points.
Features
- Trusted 11 HP Hatz diesel with electric start couples German engineering to stainless endurance.
- Real-pressure mine water moves 1,500 L/min open flow, shutting off at 30 m (43 PSI).
- Endurance-grade 316 stainless Mine Spec 3-inch wet end outlasts coated alternatives underground.
- Solids capacity of 24 mm via the open impeller handles coarse mine debris continuously.
- Trouble-free self-priming 80 mm waterways work through variable sump levels fully unattended.
- Electric start supports rapid deployment of the engine-driven package at paddock, quarry and marine sites.
- Covered by the 3 year Aussie Pumps pump warranty and 2 year Hatz engine warranty.
SPECIFICATIONS
| Max Flow | 1500 L/Min |
| Max Head | 30 m |
| Power | Hatz Diesel Electric Start Engine |
| Suitable For | Wastewater Pumping |
| Body Material | 316 Stainless Steel |
| Inlet Size | 80 mm |
| Outlet Size | 80 mm |
| Warranty | 3 Years |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
How do open impeller vanes keep fibrous matter from winding around the drive shaft in everyday paddock dewatering?
Spherical debris up to 24 mm in size clears the non-clog AISI 316 stainless steel impeller on the Aussie Pumps Stainless Steel Diesel Engine Drive B3XR-A/X (GB3XR-A-X-1B50EM) without obstructing discharge flow.
What vertical suction lift does the self priming mechanism achieve across dry starts across routine site transfer duties?
The self-priming wet end on GB3XR A X 1B50EM lifts liquid automatically from depths down to 6 m.
How does cast stainless steel metallurgy resist chemical attack from corrosive liquids when transferring harsh farm chemicals?
Cast 316 stainless steel wetted surfaces suit the GB3XR-A/X/1B50EM for demanding transfer duties.
How much liquid volume can this unit discharge at maximum speed when discharging into storage tanks?
Operating across its performance curve, the GB3XR-A/X/1B50EM discharges a maximum flow rate of approximately 1500 L/min and develops a maximum elevation head of approximately 30 m.
What engine drive specifications and starting mechanisms are fitted to this unit without requiring electrical mains hookups?
Driven by a diesel engine, the B3XR-A/X (GB3XR-A/X/1B50EM) operates independently across remote paddocks and civil sites without mains electricity.
