SKU: GB3XRA-X-HYD
Aussie Pumps GMP GB3XRA-X-HYD 316 Stainless Steel Hydraulic Self-Priming Transfer Pump with Open Impeller
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
Chemical plants and stainless-spec marine systems run this 316 stainless 3-inch hydraulic pump where bronze is not enough, pushing up to 1,500 litres a minute, shutting off at 31 metres through full stainless waterways. Maximum corrosion authority. Beyond-bronze corrosion authority is GB3XRA-X-HYD in full 316 stainless steel.
Open-discharge capacity reaches 1,500 L/min with shut-off at 31 m (44 PSI). The 316 stainless steel wet end with open non-clog impeller runs a carbon/alumina mechanical seal with nitrile rubber.
Where bronze is not enough, 21 cm3/rev at 150 bar (7 kW) drives full 316 stainless waterways, shutting off at 31 metres at 1,500 litres a minute. The 80 mm ports prime from 6 m depths, while the stainless casing stays protected behind the replaceable suction port.
Use this hydraulic pump for marine pumping, mine dewatering, water transfer and fire-fighting duties. The application range suits onboard water movement and shore work as readily as site dewatering, tank-to-tank transfer and ready access to water during fire-response situations.
Features
- Beyond-bronze 316 stainless wet end with 21 cm3/rev at 150 bar (7 kW) drive suits chemical plants.
- Aggressive-liquid pressure moves 1,500 L/min open flow, shutting off at 31 m (44 PSI).
- Maximum-authority 3-inch stainless hydraulics exceed bronze wherever process chemistry demands it most.
- Stainless-spec service flows through the open non-clog impeller with carbon, alumina and nitrile sealing.
- Casing-protecting replaceable suction port with 6 m self-priming guards the stainless investment.
- At 56 kg, the package can be planned around appropriate lifting, skid or fixed-installation arrangements.
- Covered by the 3 year Aussie Pumps pump warranty.
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What chemical solutions and process fluids can this stainless pump transfer safely without suffering corrosive degradation?
High chemical compatibility on the Aussie Pumps Stainless Steel Hydraulic Semi-Trash B3XR-A/X (GB3XRA-X-HYD) allows safe transfer of fertilizers, chemical reagents, and acidic runoff through 316 stainless waterways.
What auxiliary oil specifications are required to operate the hydraulic drive during dust suppression operations?
Hydraulic oil flow from the carrier machine powers the motor on the GB3XRA-X-HYD, providing self-contained pumping without on-board petrol or diesel engines.
What fluid volume per minute and total dynamic elevation head are generated across open site lines?
Discharge performance for the GB3XRA-X-HYD yields an open flow volume of approximately 1500 L/min and reaches a maximum shut-off elevation of approximately 31 m.
Can the casing self prime from below ground tanks without a check valve in the line during everyday operations?
Built-in priming passages on the GB3XRA-X-HYD draw fluid vertically from depths up to 6 m without requiring an external foot valve once the casing is filled.
Can the wet end clear slurry solids and small stones without choking internal channels across demanding site dewatering duties?
Equipped with an open AISI 316 stainless steel semi-trash impeller geometry, the B3XR-A/X (GB3XRA-X-HYD) clears solid matter without jamming internal channels.
