Roll over image to zoom
SKU: GB4XRA/XKD625
Aussie Pumps GMP GB4XRA/XKD625 316 Stainless Steel Semi-Trash Pump with Kohler Diesel Electric Start Engine
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
Big stainless dewatering runs on Kohler power in this 4-inch 316 stainless trash pump, converting 25 diesel horsepower into up to 2,100 litres a minute, shutting off at 31 metres. Maximum stainless flow in the engine range. Maximum stainless engine flow is GB4XRA/XKD625 on 25 HP Kohler KD625 diesel.
Maximum flow holds 2,100 L/min open discharge, shutting off at 31 m head (44 PSI). The 316 stainless steel B4XR-A/X wet end with open non-clog style impeller passes 32 mm solids through 100 mm ports.
Big dewatering converts 25 Kohler horsepower into up to 2,100 litres a minute, shutting off at 31 metres through the KD625 diesel with electric start. Sump and quarry duty suits the self-priming suction behind full 100 mm ports.
This pump is specified for wastewater transfer, dust suppression, water-cart duty, fire fighting and quarry dewatering. The broad application range supports contractor and quarry work, including clearing accumulated water, filling mobile carts, supplying suppression lines and maintaining water availability for fire-response needs.
Features
- Big-site 25 HP Kohler KD625 diesel with electric start converts fuel into up to 2,100 litres a minute.
- Peak flow of 2,100 L/min, shutting off at 31 m (44 PSI) leads all stainless engine transfer.
- Maximum-flow full 316 stainless 4-inch wet end gives unrestricted corrosive flow area.
- Solids of 32 mm through the open non-clog impeller digest coarse quarry and mine debris.
- Duty-ready self-priming 100 mm ports handle sump and quarry applications continuously without attention.
- Electric start supports rapid deployment of the engine-driven package at paddock, quarry and marine sites.
- Covered by the 3 year Aussie Pumps pump warranty and 2 year Kohler engine warranty.
SPECIFICATIONS
| Max Flow | 2100 L/Min |
| Max Head | 31 m |
| Power | Kohler KD625 Diesel Electric Start Engine |
| Suitable For | Dust Suppression |
| Body Material | 316 Stainless Steel |
| Inlet Size | 100 mm |
| Outlet Size | 100 mm |
| Warranty | 3 Years |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What hydraulic delivery volume and total elevation head are rated across open site lines?
Operating across its performance curve, the Aussie Pumps Stainless Steel Diesel Engine Drive B4XR-A/X (GB4XRA-XKD625) discharges a maximum flow rate of approximately 2100 L/min and develops a maximum elevation head of approximately 31 m.
How do open impeller vanes keep fibrous matter from winding around the drive shaft across high volume transfer lines?
Equipped with an open AISI 316 stainless steel semi-trash impeller geometry, the GB4XRA XKD625 clears solid matter up to 32 mm in diameter without jamming internal channels.
What engine drive specifications and starting mechanisms are fitted to this unit during off-grid dewatering duties?
Shaft rotation on the GB4XRA/XKD625 is supplied by a diesel engine package, delivering extended run times and high torque for remote dewatering.
How rapidly do internal recirculation passages pull water from below grade trenches during everyday operations?
Vertical suction capability on the GB4XRA/XKD625 reaches up to 6 m, evacuating intake line air swiftly without requiring a flooded suction inlet.
Why is cast stainless steel selected for fertilizer decanting and chemical batching without suffering corrosive degradation?
Cast 316 stainless steel wetted surfaces suit the B4XR-A/X (GB4XRA/XKD625) for demanding transfer duties.
