SKU: QPT305SLTEDL100
Aussie Pumps Mr T Twin Skipper QPT305SLTEDL100 Aluminium 10HP Marine Fire Pump with Yanmar Diesel Engine
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
With large suction porting and twin-impeller high-pressure performance, this marine configuration is intended for bulk water transfer and high-elevation fire pumping. Epoxy body coating and bronze hydraulics ensure saltwater longevity. Engineered for proven service in severe coastal and maritime.
Hydraulic performance encompasses a maximum shut-off head of 90 m (128 PSI) at zero flow and an open-discharge flow capacity of up to 480 L/min at zero static head. Dry weight: 100 kg in roll frame. High-tensile body metallurgy resists outdoor weathering and operational casing wear.
Driven by an electric-start Yanmar L100 (10 HP) diesel engine in a protective roll frame (battery supplied separately; QPT twin-impeller models are excluded from free Geomet couplings/strainer). Ports feature 3" inlet with 3-way outlet, self-priming to 7.6 m. High-torque Yanmar diesel engine drive delivers strong fuel economy on site.
Built with stainless steel external fasteners and zinc anode protection for heavy marine service. Supported by complete technical assembly schematics, user guides, and genuine replacement component stockists through Aussie Pumps distributor networks across Australia. Complete technical assembly schematics and spare parts stockists support ongoing field operations.
Features- Twin bronze impellers deliver extra high pressure up to 90 m head (128 PSI) with 3-inch suction.
- Full epoxy body coating inside and out with sacrificial zinc anode protection.
- Electric-start Yanmar L100 (10 HP) diesel engine in a protective roll frame.
- High-output delivery producing up to 480 L/min maximum flow rate.
- Multi-port 3-inch inlet with 3-way discharge manifold for flexible fire hose deployment.
- Self-primes rapidly from 7.6 m vertical suction depth through big-belly geometry.
- Includes a 5-year Aussie Pumps warranty on the pump body and a 2-year Yanmar diesel engine warranty.
SPECIFICATIONS
| Max Flow | 480 L/Min |
| Max Head | 90 m |
| Power | Yanmar L100 Diesel Electric Start Engine |
| Suitable For | Hull Descaling |
| Body Material | Marine Grade Aluminium |
| Inlet Size | 80 mm |
| Outlet Size | 3-way (2 x 25 mm, 1 x 40 mm) |
| Warranty | 5 Years |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
Which maximum liquid volume and discharge head apply to this assembly?
The Aussie Pumps Sea Skipper Twin Impeller QPT305SLTE (QPT305SLTEDL100) generates up to approximately 480 L/min in water movement and develops a maximum head of approximately 90 m.
How does the larger suction intake enhance twin-stage high pressure output?
The three-inch suction intake on the QPT305SLTEDL100 maximizes water ingestion, feeding both impellers smoothly to maintain peak velocity across multi-nozzle deck washdown assemblies.
How are hose connections arranged on the intake and discharge ports?
Port plumbing on the QPT305SLTEDL100 is configured with 3" BSP suction intake with a 3-way discharge manifold (two 1" and one 1.5" outlets), connecting easily to delivery lines.
How deep can the suction intake be positioned below the pump casing?
Vertical suction intake on the QPT305SLTEDL100 operates from depths up to approximately 7.6 m, picking up prime reliably once primed.
Which drive engine and startup mechanism are standard equipment?
Operational drive for the QPT305SLTEDL100 is supplied by a Yanmar L100 10HP electric-start diesel engine, which starts using key-switch electric start.
