Aussie Pumps Skipper QP205SE/GX160MAR Aluminium 5.5HP Marine Transfer Pump with Honda Petrol Engine
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
Marine deck washdown, saltwater transfer, and vessel fire protection are the intended duties for this marine pump arrangement.
Hydraulic performance encompasses a maximum shut-off head of 75 m (107 PSI) at zero flow and an open-discharge flow capacity of up to 450 L/min at zero static head. The epoxy-coated marine aluminium casing houses a bronze impeller, bronze volute, sacrificial zinc anode drain plug, and ceramic/carbon mechanical seal. Mass: 30 kg. High-tensile body metallurgy resists outdoor weathering.
Driven by a Honda GX160 (5.5 HP) petrol engine with recoil start in a cold stainless steel roll frame (electric-start option includes stainless steel frame with anti-vibration mounts). Ports feature 2" inlet with 3-way outlet (2 x 1" & 1 x 1.5"), self-priming up to 7.6 m. Commercial Honda engine drive provides Steady starting torque and long operating life.
Supplied with free Geomet-treated couplings and suction strainer for immediate marine hookup. Corrosion-resistant stainless steel fasteners and zinc anode protection ensure long service life. Supported by complete spare parts stockists and schematics across regional distributor networks. Complete technical assembly schematics and spare parts are available nationwide through Aussie Pumps distribution networks.
Features- Epoxy-coated marine aluminium casing with heavy bronze impeller and bronze volute.
- Sacrificial zinc anode fitted in drain plug actively inhibits galvanic corrosion in saltwater.
- Hydraulic limits: maximum shut-off head of 75 m (107 PSI) at zero flow, with open-discharge flow capacity up to 450 L/min at zero head.
- Multi-port 3-way discharge manifold (2 x 1-inch and 1 x 1.5-inch) for flexible hose setups.
- Honda GX160 (5.5 HP) commercial petrol engine with stainless steel roll frame.
- Includes free Geomet-treated couplings and suction strainer for marine service.
- Includes a 5-year Aussie Pumps warranty on the pump body and a 3-year Honda GX engine warranty.
SPECIFICATIONS
| Max Flow | 450 L/Min |
| Max Head | 75 m |
| Power | Honda GX160 Petrol Engine |
| Suitable For | Deck Washdown |
| Body Material | Marine Grade Aluminium |
| Inlet Size | 50 mm |
| Outlet Size | 3-way (2 x 25 mm, 1 x 40 mm) |
| Warranty | 5 Years |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What specialized marine coatings protect this unit from saltwater corrosion?
Treated with a specialized marine epoxy coating and sacrificial zinc anode protection, the Aussie Pumps Sea Skipper Marine QP205SE (QP205SE/GX160MAR) resists harsh maritime salt spray and galvanic corrosion during daily sea exposure.
How effectively does this assembly draw fluid from deep pits and channels?
Vertical priming performance for the QP205SE/GX160MAR reaches up to approximately 7.6 m, evacuating air from suction lines without priming aids.
What inlet and delivery plumbing fittings come with this assembly?
The QP205SE-GX160MAR supplies 2" BSP suction intake and 3-way discharge manifold (two 1" ports and one 1.5" port), supporting direct attachment of standard suction lines.
How much liquid displacement and pressure head are rated for operation?
The QP205SE GX160MAR produces up to approximately 450 L/min in fluid displacement and up to approximately 75 m in total dynamic head.
How is shaft power provided and initiated on this pump?
Equipped with a Honda GX160 5.5HP petrol engine, the QP205SE/GX160MAR engages via manual recoil pull starter to maintain steady rpm.
