Aussie Pumps Skipper QP205SED/L48E Aluminium 4.8HP Marine Transfer Pump with Yanmar Diesel Engine
Australia-Wide
(08) 9240 2992
Official Aussie Pumps
Peace of Mind
Product Overview
Electric key start is part of this diesel marine configuration for high-pressure saltwater transfer, vessel washdown, and marine fire protection. Epoxy-coated body metallurgy, bronze internals, and zinc anode protect against salt decay. Engineered for proven service in severe coastal and maritime duties.
Hydraulic performance encompasses a maximum shut-off head of 60 m (85 PSI) at zero flow and an open-discharge flow capacity of up to 400 L/min at zero static head. Built with an epoxy-coated aluminium casing, bronze closed impeller, bronze volute, ceramic/carbon seal, and zinc anode in drain plug. Dry boxed mass: 45 kg. High-tensile body metallurgy resists outdoor weathering and operational casing wear.
Driven by an electric-start Yanmar L48 (4.8 HP) diesel engine in a free stainless steel full roll frame with anti-vibration mounts (battery supplied separately). Plumbing features 2" inlet with 3-way outlet (2 x 1" & 1 x 1.5"), self-priming lift reaching 7.6 m. High-torque Yanmar diesel engine drive delivers strong fuel economy on site.
Supplied with free Geomet-treated couplings, suction strainer, and stainless steel external fasteners for complete saltwater defense. Supported by factory technical assembly schematics, product guides, and replacement parts stockists through distributor networks across Australia. Complete technical assembly schematics and spare parts are available nationwide through Aussie Pumps distribution networks.
Features- Full internal and external epoxy body coating with bronze impeller and bronze volute.
- Sacrificial zinc anode in drain plug actively stops galvanic corrosion in marine service.
- High-pressure delivery producing 60 m maximum head (85 PSI) and 400 L/min flow.
- Electric-start Yanmar L48 (4.8 HP) diesel engine in a stainless steel roll frame (battery supplied separately).
- Multi-port 3-way discharge manifold for flexible marine hose connections.
- Includes free Geomet-treated couplings, suction strainer, and stainless steel fasteners.
- Includes a 5-year Aussie Pumps warranty on the pump body and a 2-year Yanmar diesel engine warranty.
SPECIFICATIONS
| Max Flow | 400 L/Min |
| Max Head | 60 m |
| Power | Yanmar L48 Diesel Electric Start Engine |
| Suitable For | Fire Protection |
| Body Material | Marine Grade Aluminium |
| Inlet Size | 50 mm |
| Outlet Size | 3-way (2 x 25 mm, 1 x 40 mm) |
| Warranty | 5 Years |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What motor platform and ignition starting mechanism are fitted?
Driven via a Yanmar L48 4.8HP electric-start diesel engine, the Aussie Pumps Sea Skipper Marine QP205SED (QP205SED/L48E) gets moving promptly through turnkey electric start.
What peak volumetric discharge and total elevation are achieved?
Volumetric flow for the QP205SED/L48E peaks at approximately 400 L/min while maximum vertical head reaches up to approximately 60 m.
What plumbing connections are provided for suction and discharge lines?
The QP205SED-L48E features connection ports encompassing 2" BSP suction port and a 3-way delivery manifold (two 1" and one 1.5" ports), matching standard site hoses.
How does turnkey electric starting support onboard vessel fire safety?
The key-switch electric ignition on the QP205SED L48E allows crew members to engage high-pressure firefighting streams immediately at the turn of a switch during maritime emergencies.
How does the pump manage suction lift from low-lying water reserves?
With generous casing capacity, the QP205SED/L48E lifts water vertically from suction depths up to approximately 7.6 m.
