Shallow-well water systems and residential pressure applications often require dependable self-priming performance where intermittent air intake may occur during operation. This pressure pump is supplied with the PECO Idromat 5 ECO controller and is engineered for domestic water supply, garden transfer duties, and pressure-assisted clean water applications requiring stable suction capability.
The NGXM 2/80 utilizes a built-in ejector system supporting suction lift capability up to 9 m while assisting rapid self-priming operation. Maximum flow reaches 53.3 L/Min with head up to 43 m, allowing efficient water delivery across residential supply lines, washing applications, and shallow-well transfer systems.
An exclusive diffuser geometry combined with an integrated flow control device assists in lowering hydraulic turbulence and operational noise levels during continuous-duty operation. Improved internal air evacuation around the mechanical seal helps reduce the risk of seal stress caused by insufficient flushing and cooling under temporary abnormal operating conditions.
The compact close-coupled pump configuration simplifies installation where space is limited while improving retrofit suitability across existing water systems. Both the pump casing and casing cover are manufactured from AISI 304 stainless steel for improved corrosion resistance, while the NGXM 2/80 incorporates a Noryl PPO-GF20 impeller and hydraulic components for lightweight and durable clean water operation.
The single-phase motor operates on 230V power supply with integrated thermal protection, IP54 protection rating, and Class F insulation. Maximum permissible casing pressure reaches 8 bar while liquid temperatures up to 35°C support dependable long-term residential pumping performance.
FEATURES- PECO Idromat 5 ECO controller supporting pressure-regulated operation
- Self-priming jet pump with built-in ejector system
- Suction lift capability up to 9 m for shallow-well installations
- Exclusive diffuser with flow control device reducing hydraulic noise
- Improved air evacuation helping protect mechanical seal operation
- Compact close-coupled construction simplifying installation
- AISI 304 stainless steel casing and casing cover for corrosion resistance
- Noryl PPO-GF20 impeller supporting lightweight hydraulic performance
