Domestic water transfer systems requiring dependable self-priming performance benefit from stable water delivery where intermittent air intake or shallow suction conditions may occur during operation. This pressure pump is supplied with the PECO Idromat 5 ECO controller and is engineered for residential water supply, garden applications, and pressure-assisted clean water transfer duties.
The NGXM 3/100 incorporates a built-in ejector system supporting suction lift capability up to 9 m while assisting fast self-priming operation across shallow-well installations. Maximum flow reaches 60 L/Min with head up to 45.9 m, supporting balanced pressure performance for household transfer systems, water boosting arrangements, and above-ground supply applications.
An exclusive diffuser geometry combined with an integrated flow control device assists in lowering hydraulic turbulence and operational noise during continuous-duty operation. Improved internal air evacuation around the mechanical seal helps reduce the risk of seal stress caused by insufficient flushing and cooling under temporary abnormal operating conditions.
The compact close-coupled pump configuration simplifies installation where space is limited while improving retrofit suitability across existing water systems. Both the pump casing and casing cover are manufactured from AISI 304 stainless steel for corrosion resistance, while the NGXM 3/100 utilizes a Noryl PPO-GF20 impeller and hydraulic components supporting lightweight and durable clean water operation.
The single-phase motor operates on 230V power supply with integrated thermal protection, IP54 protection rating, and Class F insulation. Maximum permissible casing pressure reaches 8 bar while liquid temperatures up to 35°C support dependable long-term residential pumping performance.
FEATURES- PECO Idromat 5 ECO controller supporting pressure-regulated operation
- Self-priming jet pump with built-in ejector system
- Suction lift capability up to 9 m for shallow-well installations
- Exclusive diffuser with flow control device reducing hydraulic noise
- Improved air evacuation helping protect mechanical seal operation
- Compact close-coupled construction simplifying installation
- AISI 304 stainless steel casing and casing cover for corrosion resistance
- Noryl PPO-GF20 impeller supporting lightweight hydraulic performance
