Grundfos CMB 1-36 Cast Iron Pressure Boosting Pump for Domestic Use with PM1 Controller
Australia-Wide
(08) 9240 2992
Official Grundfos
Peace of Mind
Product Overview
The Grundfos CMB 1-36 is a compact pressure boosting pump designed for domestic water supply and light commercial applications. It is supplied as a complete booster unit with an integrated PM1 pressure manager, allowing automatic start and stop operation based on water demand while protecting the pump from dry running.
The pump features a robust cast iron pump housing combined with multistage stainless steel impellers (AISI 304), providing strength, corrosion resistance, and consistent performance. The integrated return valve enhances system reliability, while the compact design allows easy installation in residential water systems.
The pump delivers a rated flow of 1.7 m³/h with a corresponding head of 23.7 metres. Based on the performance curve, it achieves a maximum head of approximately 36 metres at shut-off and a maximum flow of approximately 40 L/min under low head conditions. The unit is not self-priming and supports a maximum suction lift of 1 metre.
The unit is powered by a 0.5 kW electric motor operating on a 1 x 240 V, 50 Hz supply. The PM1 controller operates with a fixed start pressure of 1.5 bar, ensuring consistent pressure boosting performance for household applications.
FEATURES
- Controller: Integrated PM1 pressure manager with automatic start/stop and dry-run protection
- Maximum Head: approx. 36 m
- Maximum Flow: approx. 40 L/min
- Construction: Cast iron pump housing with stainless steel impellers (AISI 304)
- Impellers: Multistage design (4-stage)
- Return Valve: Integrated for reliable system operation
- Suction Capability: Maximum 1 m (non self-priming)
- Maximum Operating Pressure: 10 bar
- Enclosure Class: IP55
SPECIFICATIONS
| Max Flow | 40 L/Min |
| Max Head | 36 m |
| Power | 0.5 kW / 240v |
| Rated Current | 3.3 Amps |
| Suitable For | Household Supply |
| Body Material | Cast Iron |
| Liquid Temperature | Maximum 40°C |
| Inlet Size | 25 mm |
| Outlet Size | 25 mm |
| Warranty | 24 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What fluid throughput and pressure head are developed by this pump?
You get up to 40 L/Min in flow and a maximum head of 36 m from the Grundfos CMB 1-36, depending on operating conditions.
What electrical connection and motor power run this pump?
Powered by a dedicated 0.5 kW motor, the CMB 1-36 connects to 240v mains power with a rated current draw of 3.3 Amps.
Is the pump body built to withstand harsh and corrosive liquids?
Manufactured with quality materials, the CMB-1-36 incorporates Cast Iron for dependable longevity and resistance to fluid erosion.
Which pumping tasks and system installations are ideal for this unit?
Suited for diverse installations, the CMB 1 36 performs domestic water boosting from rainwater storage tanks and municipal mains supply lines with dependable fluid propulsion.
What manufacturer warranty coverage is included with this pump?
Factory coverage on the CMB/1/36 provides an authentic 2 Years warranty for dependable long-term reliability.
