SKU: 92616914
Grundfos UNILIFT APG 40.10.A1 Cast Iron Grinder Pump for Domestic Grey Water with Vortex Semi-Open Impeller
Australia-Wide
(08) 9240 2992
Official Grundfos
Peace of Mind
Product Overview
Driven by resilient structural material choices, the Grundfos UNILIFT APG.40.10.A1 single-stage submersible pumps, designed for pumping domestic wastewater in pressurised systems, utilize an advanced hybrid casing. Engineered to thrive in domestic wastewater environments, this model incorporates a cast-iron pump housing fused with a stainless steel upper cylinder. This framework prevents rapid degradation in reactive blackwater. The structural integrity supports the professional grinder system, providing rigidity as it cuts solids into smaller pieces.
Thermodynamic behavior is managed through a lightweight motor concept. Operating on a single phase 240v supply at 5.7 Amps, the drive translates 1 kW of power to the cutting head. Mechanical shaft seals create an impermeable barrier while in-built motor protection monitors temperature. The integrated float switch allows automated cycling.
Hydraulic output remains exceptionally consistent across elevation changes. This asset generates a maximum head of approximately 26 meters, ensuring reliable upward fluid displacement. The unit manages a peak flow rate of 210 L/Min through the 40 mm discharge port, preventing internal pipe stagnation.
Deployment flexibility is critical. Operating in liquid temperatures up to 40°C, the system functions seamlessly inside an airtight odour-proof collecting tank setup to prevent gaseous leakages in basements. The semi open vortex impeller works in perfect harmony with the grinding mechanism to continuously reject debris, significantly cutting installation time.
Features
- Features an integrated float switch mechanism to enable precise automated operational cycling within collection pits
- Constructed with a specialized stainless steel upper cylinder to protect the internal electrical matrix from corrosive sewage gases
- Engineered to easily adapt to standard DN32 and DN40 pipeline structures for reduced installation complexities
- Provides a lightweight 25 kg operational profile to eliminate the need for heavy lifting equipment during maintenance
- Employs a robust semi open vortex impeller designed to aggressively manage fibrous waste without binding
- Incorporates built-in motor protection parameters that safeguard the drive module against damaging thermal spikes
SPECIFICATIONS
| Max Flow | 210 L/Min |
| Max Head | 26 m |
| Power | 1 kW / 240v |
| Rated Current | 5.7 Amps |
| Suitable For | Domestic Blackwater Removal |
| Body Material | Cast Iron |
| Liquid Temperature | Maximum 40°C |
| Outlet Size | 40 mm |
| Warranty | 24 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
How much water flow and pressure can this pump deliver?
You get up to 210 L/Min in flow and a maximum head of 26 m from the Grundfos UNILIFT APG 40.10.A1, depending on operating conditions.
What voltage supply and motor power does this pump need?
Powered by a dedicated 1 kW motor, the UNILIFT APG 40.10.A1 connects to 240v mains power with a rated current draw of 5.7 Amps.
What corrosion-resistant materials are used in the wetted components?
Manufactured with quality materials, the UNILIFT-APG-40-10-A1 incorporates Cast Iron for dependable longevity and resistance to fluid erosion.
What materials make this pump durable against corrosion and wear?
Structural defense on the UNILIFT APG 40 10 A1 is provided by a rugged high-grade alloy casing designed to withstand heavy mechanical stress.
What factory warranty backing is provided with this pumping equipment?
Factory coverage on the UNILIFT/APG/40/10/A1 provides an authentic 2 Years warranty for dependable long-term reliability.
