SKU: 59643600
Grundfos UP 20-30 N Stainless Steel Fixed Speed Circulator Pump for Hot Water Return Lines with Composite Impeller
Australia-Wide
(08) 9240 2992
Official Grundfos
Peace of Mind
Product Overview
Designed around single-speed simplicity, the Grundfos UP 20-30 N suits domestic hot water return lines where a fixed duty point covers the circulation requirement without the added complexity of a multi-speed switch. It is sized for smaller domestic loops, such as those serving single-family homes with a dedicated hot water return.
The pump achieves a maximum flow of approx. 39.8 L/Min with a maximum head up to 3 m, running at a fixed continuous speed on 90 W and 0.34 A from a 1 x 240 V supply. Because output isn't adjustable, sizing during specification is important, but the unit has no speed selector to configure over the course of its service life.
A stainless steel pump housing paired with a composite impeller makes the UP 20-30 N suitable for potable water circuits, with the wetted parts resisting corrosion in oxygenated domestic supplies. Liquid temperatures up to 110°C and system pressures to 10 bar are supported, covering both standard tank heaters and higher-temperature tankless units.
Housed to IP44 for undercover fitting, the pump has a 150 mm port-to-port length and 1 1/4 inch threaded connections that align with common domestic pipework. Impedance-protected motor construction incorporates overload protection directly into the winding, eliminating the need for external starters or relays.
FEATURES
- Fixed-speed operation with no selector switch simplifies installation and ongoing system configuration
- Stainless steel pump housing with potable water approval provides corrosion resistance in domestic hot water supplies
- Composite impeller construction offers consistent hydraulic performance in hot water recirculation applications
- Impedance-protected motor design incorporates overload protection without external protection devices
- Maximum system pressure rating of 10 bar accommodates both standard domestic and higher-pressure systems
- Wetted materials certified for drinking water contact, meeting relevant potable water regulations
- 150 mm port-to-port body dimension aligns with standard domestic pipework configurations
SPECIFICATIONS
| Max Flow | 39.8 L/Min |
| Max Head | 3 m |
| Power | 0.09 kW / 240v |
| Rated Current | 0.34 Amps |
| Suitable For | Tankless Water Heating |
| Body Material | Stainless Steel |
| Liquid Temperature | Maximum 110°C |
| Inlet Size | 32 mm |
| Outlet Size | 32 mm |
| Warranty | 24 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What materials protect the wetted parts against aggressive chemical attack?
High-grade Stainless Steel components in the Grundfos UP 20-30 N protect internal passages against corrosive fluid contact.
What electrical supply parameters are needed for this pump motor?
It operates on 240 V power, with the UP 20-30 N utilizing a durable 0.09 kW motor rated at 0.34 Amps.
What water temperature range and installation depth are supported?
Thermal ratings for the UP-20-30-N accommodate working liquid temperatures up to 110°C under standard operating pressure.
How much pumping height does this pump provide?
Pumping performance for the UP 20 30 N provides up to 3 m of vertical dynamic lift, depending on system friction and line sizing.
What peak fluid displacement volume can this pump deliver?
Moving liquid through the system, the UP/20/30/N achieves a maximum flow of up to approx. 39.8 L/Min at maximum flow.
