Grundfos UPS 25-120 Cast Iron Three Speed Circulator Pump for Space Heating with Composite Impeller
Australia-Wide
(08) 9240 2992
Official Grundfos
Peace of Mind
Product Overview
Multi-storey risers and systems with unusually long branch runs require more head than any other pump in the UPS cast iron range can generate. The Grundfos UPS 25-120 sits at the top of that lineup, purpose-built for closed-loop circuits where vertical lift or extended pipe resistance would otherwise limit circulation to the highest points of the system.
At full speed the pump delivers approx. 60.7 L/Min with a maximum head up to 12 m, the tallest rating among the UPS 25 models, powered by up to 230 W and 0.99 A on a 1 x 240 V supply. Three selectable speeds step power from 125 W upward, allowing the pump to be run below maximum on shorter branches while retaining full head capacity where the riser demands it.
The canned rotor motor lubricates its own bearings using the circulating heating water, a design carried through the entire UPS range that removes the mechanical shaft seal. Liquid temperature tolerance runs from -25°C up to 95°C, slightly lower than the 110°C rating of other UPS 25 variants, reflecting its focus on standard heating rather than higher-temperature boiler applications.
An IPX2D enclosure provides contact protection, and internal thermal protection is built into the motor winding. At 180 mm port-to-port with 1 1/2 inch connections, it retains the same physical footprint as the other 180 mm UPS 25 models, making it a direct upgrade path where an existing installation needs more head without a larger bore.
FEATURES
- Tallest head rating in the UPS 25 range at up to 12 m for multi-storey risers and systems with unusually long branch runs
- Three-speed selector permits field adjustment from 125 W to 230 W
- Canned rotor design with self-lubricating bearings eliminates the mechanical shaft seal
- Internal thermal motor protection safeguards the winding against overload in continuous operation
- Cast iron housing specified for closed-loop heating applications where potable water approval is not required
- Liquid temperature tolerance from -25°C to 95°C for standard heating applications and cold plant room environments
- IPX2D enclosure rating provides protection against dripping water and contact in service environments
- 180 mm port-to-port body dimension matches the footprint of other UPS 25 models
SPECIFICATIONS
| Max Flow | 60.7 L/Min |
| Max Head | 12 m |
| Power | 0.23 kW / 240v |
| Rated Current | 0.99 Amps |
| Suitable For | Tall Riser Heating |
| Body Material | Cast Iron |
| Liquid Temperature | -25°C to 95°C |
| Inlet Size | 40 mm |
| Outlet Size | 40 mm |
| Warranty | 24 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What is the maximum water volume this pump can discharge?
Fluid evacuation capacity for the Grundfos UPS 25-120 peaks at approximately 60.7 L/Min, providing dependable high-volume drainage.
What materials are used to construct the pump casing and impeller?
Manufactured with quality materials, the UPS 25-120 incorporates Cast Iron for dependable longevity and resistance to fluid erosion.
What are the power requirements and running amperage for this pump?
Under full load conditions, the motor in the UPS-25-120 delivers 0.23 kW on a 240 V line drawing 0.99 Amps.
What fluid temperature limits and immersion depths are rated for this unit?
Tested for thermal durability, the UPS 25 120 tolerates working fluid temperatures -25°C to 95°C.
What is the maximum vertical lift capacity of this pump?
Fluid elevation through vertical risers reaches up to 12 m with the UPS/25/120 under standard duty points.
