Grundfos UPS 32-80N Stainless Steel Three Speed Circulator Pump for Hot Water Return Lines with Composite Impeller
Australia-Wide
(08) 9240 2992
Official Grundfos
Peace of Mind
Product Overview
When a heating or hot water system is specified with wider bore pipework to handle greater volume, a pump with a matching connection size is required to avoid unnecessary flow restriction. The Grundfos UPS 32-80N is designed for those systems, with a 2 inch connection that reduces flow resistance at equivalent volumes.
At full speed the pump delivers approx. 182 L/Min with a maximum head up to 8 m of maximum head, with three selectable settings stepping power from 140 W up to 230 W and current reaching 1.01 A on a 1 x 240 V supply. The wider 2 inch connection reduces flow restriction compared to the 1 1/2 inch models at equivalent volumes, which matters as zone count and pipe run length increase.
The canned rotor construction shared across the UPS N range removes the mechanical shaft seal, with bearings lubricated by the circulating water. Stainless steel wetted parts and a composite impeller keep the pump suitable for potable hot water while tolerating liquid temperatures from -25°C up to 110°C.
An IPX2D enclosure provides contact protection, and internal thermal protection is built into the motor winding. The 180 mm port-to-port body matches the dimensional footprint of the smaller UPS 25 series, so specification decisions largely come down to bore size and head requirement.
FEATURES
- Larger 2 inch connection reduces flow restriction and velocity at equivalent volumes
- Three-speed selector provides performance adjustment from 140 W to 230 W
- Canned rotor construction integrates the pump and motor without a mechanical shaft seal
- Stainless steel housing and composite impeller with potable water approval and liquid temperature tolerance from -25°C to 110°C
- Internal thermal motor protection safeguards the winding against overload in continuous service
- IPX2D enclosure rating provides protection against dripping water and contact in service environments
- Self-lubricating bearing design supports continuous operation without routine maintenance intervention
- 180 mm port-to-port body dimension matches the footprint of the smaller UPS 25 series
SPECIFICATIONS
| Max Flow | 182 L/Min |
| Max Head | 8 m |
| Power | 0.23 kW / 240v |
| Rated Current | 1.01 Amps |
| Suitable For | Multi-Zone Heating |
| Body Material | Stainless Steel |
| Liquid Temperature | -25°C to 110°C |
| Inlet Size | 50 mm |
| Outlet Size | 50 mm |
| Warranty | 24 Months |
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What is the maximum water volume this pump can discharge?
Moving liquid through the system, the Grundfos UPS 32-80N achieves a maximum flow of up to approx. 182 L/Min at maximum flow.
Is the pump body built to withstand harsh and corrosive liquids?
Built with a resilient Stainless Steel body, the UPS 32-80N maintains material durability against fluid abrasion and wear.
What are the power requirements and running amperage for this pump?
Connecting across 240 V lines, the UPS-32-80N draws approximately 1.01 Amps with an efficient 0.23 kW motor.
How deep can this pump be submerged underwater?
Fluid media ranging -25°C to 110°C can be circulated through the UPS 32 80N without thermal breakdown.
What is the maximum vertical lift capacity of this pump?
To overcome vertical elevation resistance, the UPS/32/80N develops a maximum pumping head of approximately up to 8 m.
