Pedrollo TOP-1-Manual Technopolymer Manual Submersible Drainage Pump for Basement Drainage with Noryl Impeller
Australia-Wide
(08) 9240 2992
Official Pedrollo
Peace of Mind
Product Overview
Basements and small residential cellars prone to clear water ingress require the Pedrollo TOP-1-Manual for effective dewatering. This technopolymer unit is intended for domestic emergency use, providing a portable solution for the evacuation of rooms or garages. The bottom-mounted suction filter allows the pump to drain liquid down to a level of 14 mm above the floor surface in manual operation modes.
Hydraulic delivery is driven by a 0.25 kW single-phase motor running at 240v, achieving a maximum flow rate of up to 160 L/Min. Drawing a rated current of 1.3 Amps, the system delivers up to 6 m head. The internal electric motor is designed for continuous S1 duty, with the pumped liquid providing continuous motor cooling during operation.
Processing of clean water is managed by a single Noryl impeller. The design permits the passage of suspended solids up to 10 mm in diameter, making the pump suitable for domestic drainage applications. This simple and robust hydraulic design provides reliable water transfer when clearing flooded residential areas.
Mechanical construction features a high-strength technopolymer pump body and suction filter, combined with an AISI 304 stainless steel motor casing for corrosion resistance. Moisture protection is provided by a double mechanical seal arrangement with an interposed oil chamber to protect the motor shaft against water ingress. The motor is further protected by Class F insulation and winding-embedded thermal contacts to trigger a safety shut-off during overheating.
FEATURES
- Technopolymer pump body and suction filter designed for high impact and corrosion resistance.
- Noryl GFN2V impeller providing reliable hydraulic performance for domestic clear water drainage.
- Compact 0.25 kW single-phase motor pulling 1.3 Amps at 240v for continuous service duty.
- Double mechanical seal system with an oil chamber protecting the motor shaft against water ingress.
- AISI 304 stainless steel motor casing and suction plate for enhanced structural durability.
- Draining capability down to 14 mm above ground level for efficient removal of basement water.
- Winding-integrated thermal overload protector for automatic motor safety in high-heat conditions.
- Resin-sealed handle assembly with 5 metres of standard power cable for flexible manual deployment.
SPECIFICATIONS
| Max Flow | 160 L/Min |
| Max Head | 6 m |
| Power | 0.25 kW / 240v |
| Rated Current | 1.3 Amps |
| Suitable For | Basement Drainage |
| Body Material | Technopolymer |
| Liquid Temperature | Maximum 40°C |
| Outlet Size | 32 mm |
| Warranty | 24 Months |
Documents
Warranty & Returns
All products supplied by Foundation Pumps are covered by a minimum 12-month warranty unless otherwise stated. Some brands may offer longer manufacturer warranties. Warranty covers manufacturing defects, faulty materials and workmanship under normal use.
- Products must be installed correctly and in accordance with the manufacturer’s instructions.
- Warranty does not cover incorrect installation, misuse, dry running, normal wear and tear, unauthorised repairs or damage caused by external factors.
- Proof of purchase, photos, videos and installation details may be requested when assessing a warranty claim.
- The customer is responsible for returning the product to Foundation Pumps or the nominated service centre unless otherwise agreed.
- Removal, reinstallation, labour and associated site costs are generally the customer’s responsibility unless required under Australian Consumer Law.
- Change-of-mind returns may be accepted within 30 days provided the product is unused, uninstalled and returned in its original packaging.
- Customers are responsible for return freight costs for change-of-mind returns.
- Restocking fees may apply to special-order, bulky or non-stocked products.
- Used, installed or specially ordered products may not be eligible for change-of-mind returns.
- If a product arrives damaged or faulty, please contact Foundation Pumps as soon as possible so we can assist with the appropriate repair, replacement or refund.
Your rights under Australian Consumer Law are not affected.
What situations is this manual drainage pump intended for?
The pump is intended for clear-water ingress in basements, cellars, rooms and garages, providing portable emergency dewatering with the TOP-1-MANUAL.
How close to the floor can it drain water?
A bottom-mounted suction filter lets the pump remove water to 14 mm above the floor, helping the TOP 1 MANUAL reduce residual water.
What motor rating and flow capacity are provided?
A 0.25 kW single-phase motor operates at 240 V and provides a maximum flow of 160 L/min, giving the TOP-1-MANUAL practical drainage capacity.
What solids passage is supported by the pump?
The Noryl impeller handles clean water containing suspended solids up to 10 mm, while the TOP 1 MANUAL remains intended for suitable clear-water drainage.
Which materials and motor protections are included?
A technopolymer body and stainless steel motor casing support corrosion resistance, while double mechanical sealing and thermal overload protection safeguard the TOP-1-MANUAL.
