Davey Microlene 20PS10 Polyspun 20 Micron 10" Replacement Water Filter Cartridge

Operational load challenges in beverage processing and industrial bottling facilities require specialized prefiltration to manage fluid quality. The Davey Microlene 20PS10 is a 20 micron polyspun sediment cartridge designed for drinking water systems and prefiltration applications. It is suitable for installation in compatible standard 10 inch filter housings measuring 254 mm by 64 mm. This unit functions as a primary filtration stage ahead of sub-micron filters or Reverse Osmosis units to capture large suspended solids.

Constructed from 100 percent food grade polypropylene, the housing utilizes thermally bonded fibers to create a rigid internal structure. The manufacturing process involves no chemical binders, gaskets, fillers, or center cores, which results in a clean filter media with no loose fibers. The unit is specified for liquid temperatures up to 63 degrees Celsius and releases no surfactants during operation. Every cartridge consists of thousands of interlocked fibers to inhibit media migration downstream.

Technical performance is specified for a flow rate of 34 L/Min to capture rust, sand, silt, and algae from the supply. The internal path utilizes a 20 micron nominal rating to trap particulate matter while maintaining a low pressure drop across the system. As a passive filtration component, it requires no electrical supply or motor drive to function. The physical configuration is designed for installation in compatible 10 inch filter housings measuring 254 mm in length.

Hygienic performance is managed through a 12-month replacement cycle recommended by the manufacturer to maintain purity standards. Polypropylene construction provides chemical resistance and does not impart taste, odour or colour to the filtered liquid. The depth filtration architecture achieves a high dirt holding capacity by trapping particles throughout the thickness of the media to protect downstream equipment. It is intended for compatible cold water filtration applications.

• Micron rating is specified at 20 microns nominal for mechanical filtration
• Manufactured from 100 percent pure food grade polypropylene fibers
• Suitable for liquid temperatures up to 63 degrees Celsius maximum
• Designed with thermally bonded fibers to inhibit media migration
• Fits compatible standard 10 inch housings measuring 254 mm
• Provides depth filtration architecture for high dirt holding capability
• Construction includes no gaskets, binders, fillers, or surfactants
