Davey Microlene 20PS10J Jumbo 20 Micron 10" Replacement Water Filter Cartridge

Internal fluid velocity paths in high-flow jumbo systems are managed by the Davey Microlene 20PS10J large diameter sediment cartridge. This unit is designed for whole-house filtration, the beverage industry, and industrial prefiltration before Reverse Osmosis units. It is designed for compatible 10 inch Jumbo housings with approximately 114 mm diameter. The large diameter allows for higher flow rates and dirt holding capacity than standard 2.5 inch cartridges in diverse facilities managing high sediment loads.

Manufactured from 100 percent pure food grade polypropylene, the housing utilizes thousands of interlocked thermally bonded fibers. The construction process excludes the use of gaskets, binders, fillers, surfactants, or center cores. This design is intended to limit fiber migration and contaminant release when the system experiences surges in flow or pressure. The media meets regulatory guidelines for potable water use and structural purity. It has no chemical residue or surfactants to be concerned about during standard operation.

Mechanical specifications include a flow rate of 84 L/Min for high-demand residential or commercial facilities. The fluid path utilizes a 20 micron nominal rating to trap suspended solids such as sand, silt, rust, and algae. It is a passive mechanical filter that operates without electrical power or motor drive systems. The unit is specified for liquid temperatures up to 63 degrees Celsius and is intended for compatible cold water filtration applications. The physical configuration is designed for 10 inch Jumbo filter housings.

Maintenance requirements are managed by the jumbo depth filtration architecture which achieves a high dirt holding capacity. Polypropylene construction provides chemical resistance and is suitable for applications requiring hygienic filtration. A 12-month replacement cycle is recommended to maintain the integrity of the filtered drinking water supply. The cartridge fits compatible 10 inch Jumbo housings and does not impart taste, odour or colour to the processed liquid stream. It features a white finish with no end caps.

• Micron rating is specified at 20 microns nominal for sediment capture
• Manufactured from 100 percent pure food grade polypropylene fibers
• Sized for 10 inch Jumbo housings measuring 254 mm by 114 mm
• Flow rate is specified at 84 L/Min for high flow systems
• Suitable for liquid temperatures up to 63 degrees Celsius maximum
• Designed for 10 inch Jumbo housings with approximately 114 mm diameter
• Provides depth filtration architecture for high dirt holding capability
