Davey Microlene 5PS10J Jumbo 5 Micron 10" Replacement Water Filter Cartridge

Safety protection containment for high-flow fine sediment removal is provided by the Davey Microlene 5PS10J polyspun jumbo cartridge. This model is designed for whole-house sediment removal, food processing industries, and laboratory environments. It is designed for compatible 10 inch Jumbo housings with approximately 114 mm diameter. The unit provides fine mechanical filtration ahead of sub-micron filters in facilities where low contamination levels are required for fluid management infrastructure.

Constructed from 100 percent pure food grade polypropylene, the cartridge features a thermally bonded fiber matrix. The manufacturing design eliminates the need for gaskets, chemical binders, fillers, or center cores to maintain fluid purity. This architectural choice is designed to inhibit media migration during fluctuations in water line pressure. The unit is clean with no extractables and meets regulatory guidelines for food contact use. Thousands of fibers are interlocked for stability and integrity within the housing assembly.

Fluid management metrics include a flow rate capacity of 76 L/Min for jumbo housing installations. The internal fluid path utilizes a 5 micron nominal rating to remove suspended particles like silt, rust, sand, and algae. This is a passive mechanical filtration component that functions without electrical supply, motors, or drives. The unit is rated for liquid temperatures reaching 63 degrees Celsius and is intended for compatible cold water filtration applications. It is suitable for fine sediment prefiltration in jumbo systems.

Hygienic performance is provided by the polypropylene media which offers chemical resistance and is suitable for diverse industrial applications. The jumbo depth filtration architecture allows for high dirt holding capacity, supporting a recommended 12-month replacement interval. The cartridge fits compatible 10 inch Jumbo housings and is designed for simple maintenance. It does not impart taste, odour or colour to the liquid stream while removing suspended solids. It fits standard 114 mm diameter housings.

• Micron rating is specified at 5 microns nominal for fine filtration
• Manufactured from 100 percent pure food grade polypropylene media
• Sized for 10 inch Jumbo housings (254 mm length, 114 mm diameter)
• Flow rate is specified at 76 L/Min for high capacity
• Suitable for liquid temperatures up to 63 degrees Celsius maximum
• Designed for 10 inch Jumbo housings with approximately 114 mm diameter
• Utilizes thermally bonded fibers to limit media release downstream
