Davey Microlene PPAC10 Pleated Carbon 10 Micron 10" Replacement Water Filter Cartridge

A primary structural material choice for combined sediment and chemical reduction is the Davey Microlene PPAC10 pleated carbon cartridge. This unit is designed for rainwater applications, closed loop streams, and post Reverse Osmosis polishing. It is suitable for installation in compatible standard 10 inch filter housings measuring 254 mm by 64 mm. The model is utilized in residential and commercial settings where sediment removal is combined with taste and odour reduction for fluid management infrastructure.

Constructed using the specified carbon impregnated media and cartridge materials, the filter features Powdered Bonded Activated Carbon impregnated on a pleated polyester media. This unique pleated architecture provides a large filtration area that allows for higher flow rates than traditional carbon cartridges. The design is specified for the reduction of chlorine and sediment from the water supply. This construction includes grey end caps and maintains a rigid structure within the housing. It features a 10 micron nominal rating.

Fluid flow specifications include an optimal flow rate of 3.8 L/Min for reduction and a maximum flow rate of 20 L/Min. The internal fluid path utilizes a 10 micron nominal rating to capture suspended solids and particulate matter such as sand, silt, and rust. As a passive filtration component, the unit operates without an electrical motor or drive configuration. It is rated for liquid temperatures reaching 52 degrees Celsius and is strictly intended for compatible cold water filtration applications. The unit features black media with grey end caps.

Hygienic performance is managed through a replacement cycle based on cartridge condition, water quality and reduced filtration performance. The large surface area of the pleated media is suitable for rainwater systems where higher sediment levels are common and require polishing. This unit should be flushed upon installation to clear any loose carbon fines from the impregnated polyester. The cartridge fits compatible standard 10 inch housings and does not impart unwanted taste, odour or colour to the processed liquid stream.

• Micron rating is specified at 10 microns nominal for sediment capture
• Constructed from Powdered Bonded Activated Carbon on pleated polyester
• Designed with a large filtration area for higher flow rate capacity
• Maximum flow rate is specified at 20 L/Min for fluid distribution
• Optimal flow rate for reduction is specified at 3.8 L/Min
• Suitable for liquid temperatures up to 52 degrees Celsius maximum
• Fits compatible standard 10 inch housings with 64 mm diameter
