Davey Microlene PPAC20J Jumbo Pleated Carbon 10 Micron 20" Replacement Water Filter Cartridge

Long-term operating cost scaling in high-flow commercial facilities is addressed by the Davey Microlene PPAC20J extended jumbo pleated carbon cartridge. This model is designed for high-flow commercial rainwater systems, industrial closed loops, and final polishing stages. It is suitable for installation in compatible 20 inch Jumbo filter housings measuring approximately 508 mm by 114 mm. The extended length provides maximum surface area for the reduction of taste, odour, and chlorine in high-demand fluid management.

Constructed using the specified carbon impregnated media and extended jumbo cartridge materials, the filter utilizes Powdered Bonded Activated Carbon impregnated on a pleated polyester media. This construction provides a high surface area that allows for higher flow rates than traditional canister-style carbon cartridges. The design is specified for the reduction of chlorine and sediment. The unit features grey end caps and a rigid internal structure to maintain performance during pressure fluctuations in the supply line.

Mechanical metrics include an optimal flow rate of 13 L/Min for reduction and a maximum flow rate of 112 L/Min for high-capacity distribution. The internal mechanical path achieves a 10 micron nominal rating for the capture of sand, silt, and rust particles. This is a passive purification device that operates without electrical supply or motor configurations. The unit is rated for liquid temperatures reaching 52 degrees Celsius and is strictly intended for compatible cold water filtration applications for processed water output.

Hygienic performance is managed through the replacement interval recommended by the manufacturer to maintain purity standards. A 12-month replacement interval is recommended to maintain the performance standards of the rainwater distribution system. The large surface area of the pleated media is suitable for systems where higher sediment levels are common and require polishing. The unit should be flushed after installation to clear carbon fines from the media. It fits compatible 20 inch Jumbo housings and does not impart unwanted taste.

• Micron rating is specified at 10 microns nominal for sediment capture
• Constructed from Powdered Bonded Activated Carbon on pleated polyester
• Designed with a large filtration area for higher flow rate capacity
• Maximum flow rate is specified at 112 L/Min for high volume use
• Optimal flow rate for reduction is specified at 13 L/Min
• Suitable for liquid temperatures up to 52 degrees Celsius maximum
• Fits compatible 20 inch Jumbo housings with 114 mm diameter
