MATelec FPC-12706 Wireless Tank Level Indicator with 4-20mA Radio Transmitter & Receiver (500m Range)

Transmitting tank depth measurements across properties without physical signal cables simplifies remote reservoir oversight. The MATelec FPC-12706 Tank Level Indicator combines a mains-powered radio transmitter panel and a digital display receiver panel to provide wireless hydrostatic level monitoring.

A submersible 316 stainless steel hydrostatic pressure transducer installed at the storage tank connects to the outdoor transmitter panel. The transmitter converts the 4-20mA sensor signal and broadcasts an encrypted radio burst across a 500-meter line-of-sight range to the indoor receiver panel, which displays real-time depth, percentage full, or volume in Litres on a digital LED process meter.

Both transmitter and receiver panels operate from single-phase 230Vac mains power supplies, utilizing internal low-voltage regulation to drive sensor loops and radio transceivers. Both enclosures are constructed from powder-coated mild steel measuring 300 x 300 x 150 mm each, carrying weatherproof protection ratings.

Removable bottom gland plates on both panels facilitate neat conduit and cable termination. The package comes complete with the transmitter panel, receiver panel, external antennas, a 316 stainless steel hydrostatic transducer (0 to 4 m rating) with 24 m of vented cable, and two 1.5 m 10 Amp mains power cords.

Features

• Paired transmitter and receiver panels housed in 300 x 300 x 150 mm powder-coated steel enclosures
• Wireless radio communication transmitting hydrostatic tank level data across a 500-meter range
• Digital LED process meter on receiver panel configurable for depth (m/mm), percentage, or Litres
• Single-phase 230Vac power operation on both panels with internal low-voltage sensor power
• Supplied with a 316 stainless steel potable water hydrostatic transducer (0-4 m calibration)
• Includes 24 m of vented submersible sensor cable and two external radio antennas
• Removable bottom gland plates and two factory-fitted 10 Amp 3-pin 1.5 m power supply leads
