Orange Pumps CJ750-SW57 Cast Iron Shallow Well Pressure Pump for Farm Water Supply with 60 Litre Tank

Site-wide distribution and multi-trough supply are the intended applications for this three-phase jet-driven pressure pump. It is engineered for farm properties requiring an automated 415v solution for moving clean water from dams or shallow wells. The 60 litre pressure tank provides the largest pressure tank option in the range, ensuring stable pressurised supply to multiple points with high efficiency.

The unit features a 1.5 kW motor drawing 3.5 Amps per phase on a 415v three-phase power supply for stable performance. Hydraulic characteristics include reaching a maximum head of approximately 58 m and a maximum flow rate of 122 L/Min. This balanced performance profile makes it ideal for facilities that manage simultaneous irrigation and livestock watering tasks automatically.

Equipped with the WK-CJ30-50 water kit and a Type D mechanical switch, the system utilizes a 60 litre pressure tank for automated operation. Its internal SW57 injector works with the jet and venturi design to purge air from the casing. The 60 litre tank provides increased draw-off capacity to further reduce cycling, extending the life of the motor and saving energy.

Construction incorporates a solid cast iron body and a double race bearing system designed for mechanical longevity. The Type D mechanical switch is engineered without sensitive electronics, providing high resistance to power surges or lightning strikes typical of rural sites. The assembly handles liquid temperatures up to 65°C and includes a 2-year Orange Pumps warranty.

FEATURES

• Solid cast iron construction ensures the system remains a durable fixture in harsh outdoor agricultural and farm environments.
• 60 litre pressure tank provides increased water draw-off to effectively minimize pump cycling and reduce wear.
• WK-CJ30-50 water kit comes fully assembled with a stainless steel barrel union for ease of priming and service.
• Type D mechanical switch is designed for high electrical tolerance against surges and voltage spikes in remote farm properties.
• SW57 injector configuration delivers an optimal performance curve suitable for both pressurised distribution and transfer.
• Double race bearing assembly shared across two rows distributes mechanical loads for improved longevity in high heat.
• Stainless steel motor shaft provides corrosion resistance.
• Large oval casing holds ample water around the impeller to assist with self-priming.
