Subsurface water retrieval for farming properties utilizes the Orange Pumps CJ850-3P-DW32-15-T60 deep well system to tap underground aquifers. Operating with the down-bore DW32-15 thermoplastic injector assembly, the configuration handles mineralized deep well supplies without clogging. Typical uses include stock watering troughs, light crop irrigation, and supplying clean water to homestead storage tanks.
Hydraulic specifications for this CJ850-3P-DW32-15-T60 deep well model indicate suction performance at deep water levels. Featuring a 2.4 kW / 415v power rating, the motor maintains approximately 82 m maximum head and approximately 55 L/Min maximum flow. The unit draws a continuous rated current of 5 Amps under standard load.
The CJ850-3P-DW32-15-T60 incorporates a matched jet and venturi configuration that fits the down-bore DW32-15 thermoplastic injector parameters. Highly polished internal paths inside the submerged injector kit limit flow resistance and water swirling. The close-coupled motor integration maintains rigid alignment to protect internal rotating components from mechanical strain.
The physical build of the CJ850-3P-DW32-15-T60 includes a rugged Cast Iron housing featuring 40 mm suction and 32 mm discharge ports. Standard fittings provided include a brass 5-way tee and a stainless steel barrel union for servicing. A heavy-duty pressure switch and gauge monitor operations
FEATURES
- Compatible with optional horizontal offset flanges for installation away from the vertical borehole line.
- Supplied with professional Philmac foot valve and heavy-duty hose clamps for secure down-bore poly piping.
- Integrated solid brass 5-way tee houses the pressure switch, pressure gauge, and discharge fittings securely.
- Supplied stainless steel barrel union simplifies priming, down-bore piping connection, and on-site servicing.
- Type D automatic pressure switch includes heavy-duty relay contacts for automatic system starting control.
- Submerged down-bore injector features zero moving parts to eliminate electrical risks below ground level.
