Zodiac eXO MID pH iQ 25g/h Salt Water Chlorinator for mineral salt pools with Long-life RP cell

Engineering a highly stable internal fluid velocity path is paramount when dealing with sensitive, automated chemical dosing arrays. The eXO MID-pH iQ 25g/h from Zodiac successfully integrates these precise hydraulic configurations to manage continuous circulation stability. Operating smoothly alongside the eXO MID-pH iQ - Includes pH Sensor framework, this sophisticated unit channels pressurized water flows systematically to prevent localized turbulence. By stabilizing the hydrodynamic pressure within the primary treatment zone, the equipment ensures that all added reagents are perfectly homogenized into the stream before returning to the pool.

Delving into the mechanisms of this advanced filtration component, the system excels at comprehensive acidity management within saltwater environments. Utilizing a premium grade pH sensor and doser, the logic continuously monitors absolute acidity variations. As fluid circulates over the probes, instantaneous telemetry dictates precise injection of neutralizing solutions, mitigating alkaline spikes and safeguarding sensitive pool surfaces against long-term scaling damage.

Furthermore, the unit’s core functionality revolves around a highly resilient reaction chamber designed for variable speed filter pump, lighting, and auxiliary heater control. As the system regulates the peripheral flow velocity, it actively utilizes a dedicated smart temperature sensor that safely controls chlorine output in cold water conditions. This critical thermal mitigation protocol is specifically engineered to assist in protecting the main cell against excessive wear and tear during off-season operations, guaranteeing consistent oxidization potential while extending the lifespan of the critical internal metallic plates.

Verifying strict operational tolerances, this specialized equipment requires a Single-phase 240 V connection, cleanly drawing 196 W for optimal processing power. It produces a robust 25gm/h chlorine yield, rated for capacities of 90,000 litres in cool zones and 50,000 litres in warm climates. The system handles fluctuating operating salinity levels ranging from 3,500 to 10,000 ppm, providing a highly resilient platform for any standard aquatic installation.

• System operating modes are precisely adjustable by exact 10% increments from a baseline of 0% up to 100%.
• Dedicated low mode functionality offers a restricted adjustment range explicitly between 0 and 30%.
• Continuous boost mode forces operation at absolute maximum 100% capacity for a duration of 24 hours.
• Features complete iAquaLink connectivity with a built-in WiFi interface for comprehensive remote management.
• The primary electrical power pack is designed with physical dimensions of H-370mm x W-320mm x D-100mm.
• The separate RP chemical reaction cell features precise dimensions of H-160mm x W-320mm x D-110mm.

Warranty: 3 years. pH and ORP sensors - 2 years only - Peristaltic pump, tubing, one way valve etc with pH or PRO models - 1 year.
