Zodiac Tri-Xo Large 35G/H Mineral Chlorinator For Automated Sanitisation Pathways With Help Menu

Dictating optimal heavy-duty load management, the TRi-XO LARGE TRi-XO LARGE 35gm/h operates as a massive asset for residential water chemistry balancing. This high-capacity chlorinator drives robust electrolytic conversion, ensuring large volumes of water are properly treated without sudden drops in sanitiser levels.

Integrated seamlessly into the management sequence, the system relies on dynamic inbuilt software designed to configure to either traditional salt chlorination or easily CrossOver to using mineral salts. This operational flexibility makes the unit ideal for use in pool/spa combo pools, ensuring residual stability especially if you are using a blanket.

Operating smoothly within the manifold, the cell utilizes long life Reverse Polarity electrode plates, yielding an increase in cell life and decreased maintenance cycles. By reversing direct current, it automatically sheds scale. The physical equipment profile is built to be perfectly suitable for new or retrofit applications in pump rooms.

Evaluating technical data, the unit integrates into the primary flow loop utilizing robust 40 mm or 50 mm connections. It yields an exceptionally high chlorine output of 35gm/h, supporting expansive pool capacities up to 120,000 liters in cool environments. It operates optimally with an recommended salinity of exactly 4,000 ppm for peak efficiency.

• The advanced operating system features an exceptionally simple to use control interface.
• Internal programming natively integrates built in timers for fully automated scheduling.
• A high-output Boost mode rapidly elevates halogen production to handle the really hot days.
• For specialized management, a Low/Spa Mode protects smaller isolated water bodies safely.
• The heavy-duty power pack housing is precisely molded to dimensions of 330mm x 310mm x 110mm.
• The inline electrolytic cell measures strictly 320mm in length by 155mm in height and 110mm.
• Maximum supported capacity in warm climate environments reaches up to 75,000 liters.

Warranty: 3 years (1 year only on peristaltic pump, tubing, one way valve and sensors if sold with pH/PRO).
